Complete service repair workshop manual for the:

Komatsu 72-2, 75-2, 78-1, 84-2 Series Diesel Engine

  • 3D72-2
  • 3D75-2
  • 3D78-1
  • 3D84
  • 3D84-2
  • 3D84N-2
  • 4D84
  • 4D84-2

The same shop manual heavy machinery mechanics use which contains all the information needed to perform service and repairs on the complete engine.  Step by step information testing, adjusting, dis-assembly, assembly, servicing and preventative maintenance.

PDF Manual. Instant Download. No Shipping. $19.99MORE INFO
For machine details (manual available separately) see below:
ENGINEAPPLICABLE MACHINE
3D72-2 / 3TNA72E-SPC05-5, PC05-6, PC05-7, PC07-1
3D75-2 / 3TN75E-SPC10-5, PC10-6
3D78-1 / 3TNC78E-VMPC10-7, PC15-2
3D84-2-3 / 3TN84E-VMPC25-1, PC30-7
3D84N-2 / 3TN84E-VMPC15-3, PC20-7, JV40CW-C-CR-W-2
4D84-2-3 / 4TN84E-VMPC40-7, PC45-1, PC50UU-2<.a>
